Actual signals and parameters 271
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
41 PROCESS PID
SET 2
Process PID (PID1) control parameter set 2. See section
PID control on page 149.
4101 GAIN See parameter 4001 GAIN.
4102 INTEGRATION
TIME
See parameter 4002 INTEGRATION TIME.
4103 DERIVATION
TIME
See parameter 4003 DERIVATION TIME.
4104 PID DERIV
FILTER
See parameter 4004 PID DERIV FILTER.
4105 ERROR
VALUE INV
See parameter 4005 ERROR VALUE INV.
4106 UNITS See parameter 4006 UNITS.
4107 UNIT SCALE See parameter 4007 UNIT SCALE.
4108 0% VALUE See parameter 4008 0% VALUE.
4109 100% VALUE See parameter 4009 100% VALUE.
4110 SET POINT
SEL
See parameter 4010 SET POINT SEL.
4111 INTERNAL
SETPNT
See parameter 4011 INTERNAL SETPNT.
4112 SETPOINT
MIN
See parameter 4012 SETPOINT MIN.
4113 SETPOINT
MAX
See parameter 4013 SETPOINT MAX.
4114 FBK SEL See parameter 4014 FBK SEL.
4115 FBK
MULTIPLIER
See parameter 4015 FBK MULTIPLIER.
4116 ACT1 INPUT See parameter 4016 ACT1 INPUT.
4117 ACT2 INPUT See parameter 4017 ACT2 INPUT.
4118 ACT1
MINIMUM
See parameter 4018 ACT1 MINIMUM.
4119 ACT1
MAXIMUM
See parameter 4019 ACT1 MAXIMUM.
4120 ACT2
MINIMUM
See parameter 4020 ACT2 MINIMUM.
4121 ACT2
MAXIMUM
See parameter 4021 ACT2 MAXIMUM.
4122 SLEEP
SELECTION
See parameter 4022 SLEEP SELECTION.
4123 PID SLEEP
LEVEL
See parameter 4023 PID SLEEP LEVEL.
4124 PID SLEEP
DELAY
See parameter 4024 PID SLEEP DELAY.
All parameters
No. Name/Value Description Def/FbEq

ABB ACS355 Specifications

General

Input Voltage	200 V to 240 V AC, 380 V to 480 V AC
Frequency	47 Hz to 63 Hz
Control Method	Scalar control
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Modbus RTU, CANopen
Enclosure Rating	IP20
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Storage Temperature	-40°C to +70°C (-40 to +158 °F)
Humidity	95% RH (non-condensing)
Altitude	Up to 1000 m (3280 ft) without derating
