Actual signals and parameters 261
T4 Time period 4 8
T1+T4 Time periods 1 and 4 9
T2+T4 Time periods 2 and 4 10
T1+T2+T4 Time periods 1, 2 and 4 11
T3+T4 Time periods 4 and 3 12
T1+T3+T4 Time periods 1, 3 and 4 13
T2+T3+T4 Time periods 2, 3 and 4 14
T1+T2+T3+T4 Time periods 1, 2, 3 and 4 15
BOOSTER Booster 16
T1+B Booster and time period 1 17
T2+B Booster and time period 2 18
T1+T2+B Booster and time periods 1 and 2 19
T3+B Booster and time period 3 20
T1+T3+B Booster and time periods 1 and 3 21
T2+T3+B Booster and time periods 2 and 3 22
T1+T2+T3+B Booster and time periods 1, 2 and 3 23
T4+B Booster and time period 4 24
T1+T4+B Booster and time periods 1 and 4 25
T2+T4+B Booster and time periods 2 and 4 26
T1+T2+T4+B Booster and time periods 1, 2 and 4 27
T3+T4+B Booster and time periods 3 and 4 28
T1+T3+T4+B Booster and time periods 1, 3 and 4 29
T2+T3+T4+B Booster and time periods 2, 3 and 4 30
T1+2+3+4+B Booster and time periods 1, 2, 3 and 4 31
3627 TIMED FUNC 2
SRC
See parameter 3626 TIMED FUNC 1 SRC.
See parameter 3626 TIMED FUNC 1 SRC.
3628 TIMED FUNC 3
SRC
See parameter 3626 TIMED FUNC 1 SRC.
See parameter 3626 TIMED FUNC 1 SRC.
3629 TIMED FUNC 4
SRC
See parameter 3626 TIMED FUNC 1 SRC.
See parameter 3626 TIMED FUNC 1 SRC.
40 PROCESS PID
SET 1
Process PID (PID1) control parameter set 1. See section
PID control on page 149.
4001 GAIN Defines the gain for the process PID controller. High gain
may cause speed oscillation.
1.0
0.1…100.0 Gain. When value is set to 0.1, the PID controller output
changes one-tenth as much as the error value. When value
is set to 100, the PID controller output changes one hundred
times as much as the error value.
1 = 0.1
