162 Program features
Note: The jogging speed overrides the constant speeds.
Note: The jogging uses ramp stop even if parameter 2102 STOP FUNCTION
selection is COAST.
Note: The ramp shape time is set to zero during the jogging (ie linear ramp).
Jogging function uses constant speed 7 as jogging speed and
acceleration/deceleration ramp pair 2.
It is also possible to activate jogging function 1 or 2 through fieldbus. Jogging
function 1 uses constant speed 7 and jogging function 2 uses constant speed 6. Both
functions use acceleration/deceleration ramp pair 2.
 Settings
 Diagnostics
Parameter Additional information
1010 Jogging activation
1208 Jogging speed
1208/1207 Jogging speed for jogging function 1/2 activated through
fieldbus
2112 Zero speed delay
2205, 2206 Acceleration and deceleration times
2207 Acceleration and deceleration ramp shape time: Set to
zero during the jogging (ie linear ramp).
Actual signal Additional information
0302 Jogging 1/2 activation through fieldbus
1401 Jogging function status through RO 1
1402/1403/1410 Jogging function status through RO 2…4. With option
MREL-01 only.
1805 Jogging function status through DO

ABB ACS355 Specifications

General

Input Voltage	200 V to 240 V AC, 380 V to 480 V AC
Frequency	47 Hz to 63 Hz
Control Method	Scalar control
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Modbus RTU, CANopen
Enclosure Rating	IP20
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Storage Temperature	-40°C to +70°C (-40 to +158 °F)
Humidity	95% RH (non-condensing)
Altitude	Up to 1000 m (3280 ft) without derating
