Actual signals and parameters 187
SEQ PROG Start, stop and direction commands through Sequence
programming. See parameter group 84 SEQUENCE
PROG.
26
1002 EXT2
COMMANDS
Defines the connections and the source for the start, stop
and direction commands for external control location 2
(EXT2).
NOT SEL
See parameter 1001 EXT1 COMMANDS.
1003 DIRECTION Enables the control of rotation direction of the motor, or fixes
the direction.
REQUES
T
FORWARD Fixed to forward 1
REVERSE Fixed to reverse 2
REQUEST Control of rotation direction allowed 3
1010 JOGGING SEL Defines the signal that activates the jogging function. See
section Control of a mechanical brake on page 157.
NOT SEL
DI1 Digital input DI1. 0 = jogging inactive, 1 = jogging active. 1
DI2 See selection DI1. 2
DI3 See selection DI1. 3
DI4 See selection DI1. 4
DI5 See selection DI1. 5
COMM Fieldbus interface as the source for jogging 1 or 2
activation, ie control word 0302 FB CMD WORD 2 bits 20
and 21. The control word is sent by the fieldbus controller
through the fieldbus adapter or embedded fieldbus
(Modbus) to the drive. For the control word bits, see section
DCU communication profile on page 320.
6
NOT SEL Not selected 0
DI1(INV) Inverted digital input DI1. 1 = jogging inactive, 0 = jogging
active.
-1
DI2(INV) See selection DI1(INV). -2
DI3(INV) See selection DI1(INV). -3
DI4(INV) See selection DI1(INV). -4
DI5(INV) See selection DI1(INV). -5
11 REFERENCE
SELECT
Panel reference type, external control location selection and
external reference sources and limits
1101 KEYPAD REF
SEL
Selects the type of the reference in local control mode.
REF1(Hz/
rpm)
REF1(Hz/rpm) Frequency reference in rpm. Frequency reference (Hz) if
parameter 9904 MOTOR CTRL MODE setting is SCALAR:
FREQ.
1
REF2(%) %-reference 2
1102 EXT1/EXT2
SEL
Defines the source from which the drive reads the signal
that selects between the two external control locations,
EXT1 or EXT2.
EXT1
All parameters
No. Name/Value Description Def/FbEq
