358 Technical data
Ratings
Type Input Output Frame
size
ACS355- I
1N
I
1N
(480 V) I
2N
I
2,1 min/10 min
2)
I
2max
P
N
x = E/U
1)
A A A A A kW hp
1-phase U
N
= 200…240 V (200, 208, 220, 230, 240 V)
01x-02A4-2 6.1 - 2.4 3.6 4.2 0.37 0.5 R0
01x-04A7-2 11.4 - 4.7 7.1 8.2 0.75 1 R1
01x-06A7-2 16.1 - 6.7 10.1 11.7 1.1 1.5 R1
01x-07A5-2 16.8 - 7.5 11.3 13.1 1.5 2 R2
01x-09A8-2 21.0 - 9.8 14.7 17.2 2.2 3 R2
3-phase U
N
= 200…240 V (200, 208, 220, 230, 240 V)
03x-02A4-2 4.3 - 2.4 3.6 4.2 0.37 0.5 R0
03x-03A5-2 6.1 - 3.5 5.3 6.1 0.55 0.75 R0
03x-04A7-2 7.6 - 4.7 7.1 8.2 0.75 1 R1
03x-06A7-2 11.8 - 6.7 10.1 11.7 1.1 1.5 R1
03x-07A5-2 12.0 - 7.5 11.3 13.1 1.5 2 R1
03x-09A8-2 14.3 - 9.8 14.7 17.2 2.2 3 R2
03x-13A3-2 21.7 - 13.3 20.0 23.3 3 4 R2
03x-17A6-2 24.8 - 17.6 26.4 30.8 4 5 R2
03x-24A4- 2 41 - 24.4 36.6 42.7 5.5 7.5 R3
03x-31A0-2 50 - 31 46.5 54.3 7.5 10 R4
03x-46A2-2 69 - 46.2 69.3 80.9 11.0 15 R4
3-phase U
N
= 380…480 V (380, 400, 415, 440, 460, 480 V)
03x-01A2-4 2.2 1.8 1.2 1.8 2.1 0.37 0.5 R0
03x-01A9-4 3.6 3.0 1.9 2.9 3.3 0.55 0.75 R0
03x-02A4-4 4.1 3.4 2.4 3.6 4.2 0.75 1 R1
03x-03A3-4 6.0 5.0 3.3 5.0 5.8 1.1 1.5 R1
03x-04A1-4 6.9 5.8 4.1 6.2 7.2 1.5 2 R1
03x-05A6-4 9.6 8.1 5.6 8.4 9.8 2.2 3 R1
03x-07A3-4 11.6 9.7 7.3 11.0 12.8 3 4 R1
03x-08A8-4 13.6 11.4 8.8 13.2 15.4 4 5 R1
03x-12A5-4 18.8 15.8 12.5 18.8 21.9 5.5 7.5 R3
03x-15A6-4 22.1 18.6 15.6 23.4 27.3 7.5 10 R3
03x-23A1-4 30.9 26.0 23.1 34.7 40.4 11 15 R3
03x-31A0-4 52 43.7 31 46.5 54.3 15 20 R4
03x-38A0-4 61 51.2 38 57 66.5 18.5 25 R4
03x-44A0-4 67 56.3 44 66
77.0 22.0 30 R4
1)
E = EMC filter connected (metal EMC filter screw installed),
U = EMC filter disconnected (plastic EMC filter screw installed), US parametrization.
2)
Overloading not allowed through Common DC connection.
00353783.xls J

ABB ACS355 Specifications

General

Input Voltage	200 V to 240 V AC, 380 V to 480 V AC
Frequency	47 Hz to 63 Hz
Control Method	Scalar control
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Modbus RTU, CANopen
Enclosure Rating	IP20
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Storage Temperature	-40°C to +70°C (-40 to +158 °F)
Humidity	95% RH (non-condensing)
Altitude	Up to 1000 m (3280 ft) without derating
