164 Program features
A parameter which is triggered by a timed function can be connected to only one
timed function at a time.
You can use the Timed functions assistant for easy configuring. For more information
on the assistants, see section Assistants mode on page 98.
Example
Air conditioning is active on weekdays from 8:00 to 15:30 (8 a.m to 3:30 p.m) and on
Sundays from 12:00 to 15:00 (12 to 3 p.m). By pressing the extension time switch,
the air-conditioning is on for an extra hour.
Parameter Setting
3601 TIMERS ENABLE DI1
3602 START TIME 1 08:00:00
3603 STOP TIME 1 15:30:00
3604 START DAY 1 MONDAY
3605 STOP DAY 1 FRIDAY
3606 START TIME 2 12:00:00
3607 STOP TIME 2 15:00:00
3608 START DAY 2 SUNDAY
3609 STOP DAY 2 SUNDAY
3622 BOOSTER SEL DI5 (cannot be the same as parameter 3601 value)
3623 BOOSTER TIME 01:00:00
3626 TIMED FUNC 1 SRC T1+T2+B
Timed function 1
3626 TIMED FUNC 1 SRC
Timed function 2
3627 TIMED FUNC 2 SRC
1001 EXT1 COMMANDS
1002 EXT2 COMMANDS
1102 EXT1/EXT2 SEL
1201 CONST SPEED SEL
1209 TIMED MODE SEL
1401 RELAY OUTPUT 1
1402 RELAY OUTPUT 2, 1403 RELAY OUTPUT 3,
1410 RELAY OUTPUT 4 (with option MREL-01 only)
1805 DO SIGNAL
4027 PID 1 PARAM SET
4228 ACTIVATE
8402 SEQ PROG START
8406 SEQ LOGIC VAL 1
8425/35/45/55/65/75/85/95 ST1 TRIG TO ST 2 …
ST8 TRIG TO ST 2
8426/36/46/56/66/76/86/96 ST1 TRIG TO ST N …
ST8 TRIG TO ST N
