ABB ACS355 User Manual

Actual signals and parameters 281
1…6 Control and status data words
101…9999 Drive parameter
5502 FBA DATA
OUT 2
See 5501 FBA DATA OUT 1.
…… …
5510 FBA DATA
OUT 10
See 5501 FBA DATA OUT 1.
84 SEQUENCE
PROG
Sequence programming. See section Sequence
programming on page 166.
8401 SEQ PROG
ENABLE
Enables Sequence programming.
If Sequence programming enable signal is lost, the
Sequence programming is stopped, Sequence
programming state (0168 SEQ PROG STATE) is set to 1
and all timers and outputs (RO/TO/AO) are set to zero.
DISABLE
D
DISABLED Disabled 0
EXT2 Enabled in external control location 2 (EXT2) 1
EXT1 Enabled in external control location 1 (EXT1) 2
EXT1&EXT2 Enabled in external control locations 1 and 2 (EXT1 and
EXT2)
3
ALWAYS Enabled in external control locations 1 and 2 (EXT1 and
EXT2) and in local control (LOCAL)
4
All parameters
No. Name/Value Description Def/FbEq
5501 setting Data word
1 Control word
2REF1
3REF2
4Status word
5 Actual value 1
6 Actual value 2

ABB ACS355 Specifications

General

Input Voltage	200 V to 240 V AC, 380 V to 480 V AC
Frequency	47 Hz to 63 Hz
Control Method	Scalar control
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Modbus RTU, CANopen
Enclosure Rating	IP20
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Storage Temperature	-40°C to +70°C (-40 to +158 °F)
Humidity	95% RH (non-condensing)
Altitude	Up to 1000 m (3280 ft) without derating
