Actual signals and parameters 277
TIME OUT A time-out has occurred in the communication between the
adapter and the drive.
2
CONFIG
ERROR
Adapter configuration error: The major or minor revision
code of the common program revision in the fieldbus
adapter module is not the revision required by the module
(see parameter 5132 FBA CPI FW REV) or mapping file
upload has failed more than three times.
3
OFF-LINE Adapter is off-line. 4
ON-LINE Adapter is on-line. 5
RESET Adapter is performing a hardware reset. 6
5132 FBA CPI FW
REV
Displays the common program revision of the adapter
module in format axyz, where:
• a = major revision number
• xy = minor revision numbers
• z = correction letter.
Example: 190A = revision 1.90A
Common program revision of the adapter module 1 = 1
5133 FBA APPL FW
REV
Displays the application program revision of the adapter
module in format axyz, where:
• a = major revision number
• xy = minor revision numbers
• z = correction letter.
Example: 190A = revision 1.90A
Application program revision of the adapter module 1 = 1
52 PANEL COMM Communication settings for the control panel port on the
drive
5201 STATION ID Defines the address of the drive. Two units with the same
address are not allowed on-line.
1
1…247 Address 1 = 1
5202 BAUD RATE Defines the transfer rate of the link. 9.6 kb/s
1.2 kb/s 1.2 kbit/s 1 =
0.1 kbit/s
2.4 kb/s 2.4 kbit/s
4.8 kb/s 4.8 kbit/s
9.6 kb/s 9.6 kbit/s
19.2 kb/s 19.2 kbit/s
38.4 kb/s 38.4 kbit/s
57.6 kb/s 57.6 kbit/s
115.2 kb/s 115.2 kbit/s
5203 PARITY Defines the use of parity and stop bit(s). The same setting
must be used in all on-line stations.
8 NONE 1
8 NONE 1 8 data bits, no parity bit, one stop bit 0
8 NONE 2 8 data bits, no parity bit, two stop bits 1
All parameters
No. Name/Value Description Def/FbEq
