2.2.3 Paper feeding kit for MP tray
< Uninstalling Procedure >
(1) Disconnect the AC cord from the Printer.
Fig. 3-73
(2) Press the front cover release button.
(3) Open the Front cover.
(4) Remove the Drum/toner ASSY.
Fig. 3-74
Printer
A
C cord
Front cover
Drum/toner ASSY
Printer
2
3
4
<Back side>
<Front side>
