HL-5240/5250DN/5270DN/5280DW SERVICE MANUAL
Confidential
1-3
2. PARTS NAMES AND FUNCTIONS
2.1 Overview
(HL-5240/5250DN)
<Front View>
Fig. 1-1
<Rear View>
*The printer illustration is based on HL-5250DN.
Fig. 1-2
Control panel
Face-down output tray
support flap (support flap)
MP tray cover ASSY
Paper tray
Power switch
Multi-purpose tray (MP tray)
Front cover release button
Face-down output tray
Back cover
Duplex tray
(For HL-5250DN)
A
C power connecto
r
Network status LEDs
(Light emitting diodes)
(For HL-5250DN)
10/100BASE-TX port
(For HL-5250DN)
USB interface connector
DIMM cover
Parallel interface connector
Front cover
