CHAPTER 5 DISASSEMBLY AND RE-ASSEMBLY
Confidential
5-42
7.25 Gear 17/20/23
(1) Remove the Gear 23.
Fig. 5-57
(2) Remove the Gear 20.
Fig. 5-58
Gear 23
Hook
Frame L
Frame L
Gear 20
Hook
