HL-5240/5250DN/5270DN/5280DW SERVICE MANUAL
Confidential
5-63
7.34 Fan Motor 60 Unit
(1) Remove the Fan motor 60 unit from the Frame R.
Fig. 5-98
7.35 Fan Motor 60 Unit LV
(1) Remove the Fan motor 60 unit LV from the Frame R.
Fig. 5-99
Fan motor 60 unit
Frame R
Fan motor 60 unit LV
Frame R
<Right side>
