How to Configure Application Visibility and Control
Configuring Application Visibility and Control in a Wired Network
To configure application visibility and control on wired ports, follow these steps:
Configuring Visibility :
• Activate NBAR2 engine by enabling protocol-discovery on the interface using the ip nbar
protocol-disco very command in the interface configuration mode. See the section, "Enabling Application
Recognition on an Interface."
Configuring Control : Configure QoS policies based on application by
1. Creating an AVC QoS policy. See the section, "Creating AVC QoS Policy".
2. Applying AVC QoS policy to the interface. See the section, "Applying a QoS Policy to the Switch Port".
Configuring application-based Flexible Netflow :
• Create a flow record by specifying key and non-key fields to the flow.
• Create a flow exporter to export the flow record.
• Create a flow monitor based on the flow record and the flow exporter.
• Attach the flow monitor to the interface.
Protocol-Discovery, application-based QoS and application-based FNF are all independent features. They
can be configured independently or together on the same interface at the same time.
Enabling Application Recognition on an interface
To enable application recognition on an interface, follow these steps:
Procedure
PurposeCommand or Action
Enters global configuration mode.configure terminal
Example:
Step 1
Device# configure terminal
Specifies the interface for which you are
enabling protocol-discovery and enters interface
configuration mode.
interface interface-id
Example:
Device(config)# interface gigabitethernet
Step 2
1/0/1
System Management Configuration Guide, Cisco IOS XE Bengaluru 17.4.x (Catalyst 9400 Switches)
181
Configuring Application Visibility and Control in a Wired Network
How to Configure Application Visibility and Control
