PS Current Operating State : Combined
Power supplies currently active : 8
Power supplies currently available : 8
Power Summary Maximum
(in Watts) Used Available
------------- ------ ---------
System Power 3505 3505
Inline Power 0 22095
------------- ------ ---------
Total 3505 25600
In case of failure in the combined mode, each operational power supply increases its output. If the output
power does not meet system requirements and the power supply autolc shutdown command is disabled,
then all the operational power supply modules may be overloaded and go into overcurrent shutdown. All
system power is then lost. We recommend enabling the power supply autolc shutdown command.
Other valid configuration options for the combined mode:
• All installed modules are DC-input power supply modules; all modules are configured as active.
• All installed modules are AC-input power supply modules of the same capacity and with the same
AC-input voltage voltage level; all modules are configured as active.
Example: Combined Mode and State (DC-Input Only)
The table below represents the two rows of power supply slots in a Cisco Catalyst 9400 Series chassis. Power
supply slots are indicated as PS1, PS2, and so on. For this example, power supply modules of the same capacity
and type (C9400-PWR-3200DC) have been installed in slots 1 through 8.
PS4 (Active)
C9400-PWR-3200DC
PS3 (Active)
C9400-PWR-3200DC
PS2 (Active)
C9400-PWR-3200DC
PS1 (Active)
C9400-PWR-3200DC
PS8 (Active)
C9400-PWR-3200DC
PS7 (Active)
C9400-PWR-3200DC
PS6 (Active)
C9400-PWR-3200DC
PS5 (Active)
C9400-PWR-3200DC
All available power supply modules are active and sharing power and can operate at up to 100 percent capacity.
The device is in a combined operating state, because a standby power supply module is not configured. There
are no other conditions to consider for this setup.
The following is sample output of this setup (the show power privileged EXEC command):
Device# show power
Power Fan States
Supply Model No Type Capacity Status 1 2 3 4
------ -------------------- ---- -------- ------------ -----------------------
PS1 C9400-PWR-3200DC dc 3200 W active good good good good
PS2 C9400-PWR-3200DC dc 3200 W active good good good good
PS3 C9400-PWR-3200DC dc 3200 W active good good good good
PS4 C9400-PWR-3200DC dc 3200 W active good good good good
PS5 C9400-PWR-3200DC dc 3200 W active good good good good
PS6 C9400-PWR-3200DC dc 3200 W active good good good good
PS7 C9400-PWR-3200DC dc 3200 W active good good good good
System Management Configuration Guide, Cisco IOS XE Bengaluru 17.4.x (Catalyst 9400 Switches)
241
Environmental Monitoring and Power Management
Example: Combined Mode and State (DC-Input Only)
