The following example shows how to revert to the built-in protocol pack:
Device> enable
Device# configure terminal
Device(config)# default ip nbar protocol-pack
Device(config)# exit
Monitoring Application Visibility and Control
This section describes the new commands for application visibility.
The following commands can be used to monitor application visibility on the switch and access ports.
Table 18: Monitoring Application Visibility Commands on the Switch
PurposeCommand
Displays the statistics gathered by the NBAR Protocol
Discovery feature.
• (Optional) Enter keywords and arguments to fine-tune
the statistics displayed. For more information on each
of the keywords, refer to the show ip nbar
protocol-discoverycommand in Cisco IOS Quality
of Service Solutions Command Reference.
show ip nbar protocol-discovery [interface
interface-type interface-number]
[stats{byte-count | bit-rate | packet-count
| max-bit-rate}] [protocol protocol-name
| top-n number]
Displays information about policy map applied to the
interface.
show policy-map interface interface-type
interface-number
Displays statistics about all flows on the specified switch.show platform software fed active | standby
wdavc flows
Examples: Application Visibility and Control Configuration
This example shows how to create class maps with apply match protocol filters for application name:
Device# configure terminal
Device(config)# class-map match-any NBAR-VOICE
Device(config-cmap)# match protocol ms-lync-audio
Device(config-cmap)#end
This example shows how to create policy maps and define existing class maps for egress QoS:
Device # configure terminal
Device(config)# policy-map test-avc-up
Device(config-pmap)# class cat-browsing
Device(config-pmap-c)# police 150000
Device(config-pmap-c)# set dscp 12
Device(config-pmap-c)#end
This example shows how to create policy maps and define existing class maps for ingress QoS:
Device# configure terminal
Device(config)# policy-map test-avc-down
Device(config-pmap)# class cat-browsing
System Management Configuration Guide, Cisco IOS XE Bengaluru 17.4.x (Catalyst 9400 Switches)
206
Configuring Application Visibility and Control in a Wired Network
Monitoring Application Visibility and Control
