• All installed modules are DC-input power supply modules of the same capacity; one module is configured
as standby.
Example: n+1 Redundant Mode (Power Supply Modules of the Same Capacity
and Type + Normal Protected State
The table below represents the two rows of power supply slots in a Cisco Catalyst 9400 Series chassis. Power
supply slots are indicated as PS1, PS2, and so on. For this example, power supply modules of the same capacity
and type (C9400-PWR-3200DC) have been installed in slots 1 through 8. Slot 8 has the +1 standby power
supply module.
PS4 (Active)
C9400-PWR-3200DC
PS3 (Active)
C9400-PWR-3200DC
PS2 (Active)
C9400-PWR-3200DC
PS1 (Active)
C9400-PWR-3200DC
PS8 (Standby)
C9400-PWR-3200DC
PS7 (Active)
C9400-PWR-3200DC
PS6 (Active)
C9400-PWR-3200DC
PS5 (Active)
C9400-PWR-3200DC
The device meets all the required conditions for an n+1 redundant mode with a normal protected state.
• It is in an n+1 redundant mode, because one power supply module is configured as standby.
There are no other n+1 redundant mode conditions to meet, since all installed modules are DC-input
power supply modules.
• It is in a normal protected state, because:
Total standby output power (3200 W) is lesser than total active output power (22400).
and
Total active output power (22400) is greater than the required budgeted power (2030)
Device# show power
Power Fan States
Supply Model No Type Capacity Status 1 2 3 4
------ -------------------- ---- -------- ------------ -----------------------
PS1 C9400-PWR-3200DC dc 3200 W active good good good good
PS2 C9400-PWR-3200DC dc 3200 W active good good good good
PS3 C9400-PWR-3200DC dc 3200 W active good good good good
PS4 C9400-PWR-3200DC dc 3200 W active good good good good
PS5 C9400-PWR-3200DC dc 3200 W active good good good good
PS6 C9400-PWR-3200DC dc 3200 W active good good good good
PS7 C9400-PWR-3200DC dc 3200 W active good good good good
PS8 C9400-PWR-3200DC dc 3200 W standby n.a. n.a. n.a. n.a.
PS Current Configuration Mode : N+1 redundant
PS Current Operating State : Normal protected
PS Slots Configured standby : PS8
Power supplies currently active : 7
Power supplies currently available : 8
Power Summary Maximum
(in Watts) Used Available
------------- ------ ---------
