Feature IEC 61850 ANSI
Fault locator RFLO
4.5 MEASUREMENT FUNCTIONS
Measurement Function IEC 61850 ANSI
Measurement of all instantaneous & integrated values
(Exact range of measurements depend on the device model)
MET
Disturbance recorder for waveform capture – specified in samples per cycle RDRE DFR
Fault Records
Maintenance Records
Event Records / Event logging Event records
Time Stamping of Opto-inputs Yes Yes
4.6 COMMUNICATION FUNCTIONS
Feature ANSI
NERC compliant cyber-security
Front RS232 serial communication port for configuration 16S
Rear serial RS485 communication port for SCADA control 16S
2 Additional rear serial communication ports for SCADA control and
teleprotection (fibre and copper) (optional)
16S
Ethernet communication (optional) 16E
Redundant Ethernet communication (optional) 16E
Courier Protocol 16S
IEC 61850 edition 1 or edition 2 (optional) 16E
IEC 60870-5-103 (optional) 16S
DNP3.0 over serial link (optional) 16S
DNP3.0 over Ethernet (optional) 16E
SNMP 16E
IRIG-B time synchronisation (optional) CLK
IEEE 1588 PTP (Edition 2 devices only)
Chapter 1 - Introduction P543i/P545i
10 P54x1i-TM-EN-1
