Address Name Trigger Trap?

1 Date Time NO

2 IRIG-B Status YES

3 Battery Status YES

4 Active Sync source YES

5 SNTP Server 1 NO

6 SNTP Server 2 NO

7 SNTP Status YES

8 PTP Status YES

3 System Alarms

1 Invalid Message Format YES

2 Main Protection Fail YES

3 Comms Changed YES

4 Max Prop. Alarm YES

5 9-2 Sample Alarm YES

6 9-2LE Cfg Alarm YES

7 Battery Fail YES

8 Rear Communication Fail YES

9 GOOSE IED Missing YES

10 Intermicom loopback YES

11 Intermicom message fail YES

12 Intermicom data CD fail YES

13 Intermicom Channel fail YES

14 Backup setting fail YES

15 User Curve commit to flash failure YES

16 SNTP time Sync fail YES

17 PTP failure alarm YES

4 Device Mode

1 IED Mod/Beh YES

2 Simulation Mode of Subscription YES

6.3 REDUNDANT ETHERNET BOARD MIB STRUCTURE

The Redundant Ethernet board MIB uses three types of OID:

● sysDescr

● sysUpTime

● sysName

MIB structure for RSTP, DHP and SHP

Address

Name

0 CCITT

1 ISO

3 Org

6 DOD

1 Internet

P543i/P545i Chapter 22 - Communications

P54x1i-TM-EN-1 561
