GENERAL INFORMATION
1-6
LUBRICATION SYSTEM SPECIFICATIONS
Unit: mm (in)
FUEL SYSTEM SPECIFICATIONS (’02 - ’05 model)
FUEL SYSTEM SPECIFICATIONS (After ’05 model)
COOLING SYSTEM SPECIFICATIONS
ITEM STANDARD SERVICE LIMIT
Engine oil capacity At draining 0.6 liter (0.6 US qt, 0.5 lmp qt) –
At disassembly 0.7 liter (0.7 US qt, 0.6 lmp qt) –
Recommended engine oil Pro Honda GN4 4-stroke oil (U.S.A. and
Canada) or an equivalent motor oil
API service classification: SG or higher
JASO T 903 standard: MA
Viscosity: SAE 10W-30
–
Oil pump rotor Tip clearance 0.15 (0.006) 0.20 (0.008)
Body clearance 0.15 – 0.20 (0.006 – 0.008) 0.22 (0.009)
Side clearance 0.05 – 0.10 (0.002 – 0.004) 0.12 (0.005)
ITEM SPECIFICATIONS
Carburetor identification number NVK00E
[P type] NVK00F
Main jet #72
Slow jet #35 X #35
Pilot screw initial opening 2-3/4 turns out
[P type] 2-1/8 turns out
Float level 13 mm (0.5 in)
Idle speed 2,000 ± 100 rpm
Starting enrichment (SE) valve resistance (20°C/68°F) 2.8 – 5.2 Ω
Throttle grip free play 2 – 6 mm (1/16 – 1/4 in)
ITEM SPECIFICATIONS
Carburetor identification number ’06 – ’07 model NVK00J
After ’07 model NVK00K
Main jet #72
Slow jet #35 X #35
Pilot screw initial opening 2-1/4 turns out
Float level 13 mm (0.5 in)
Idle speed 2,000 ± 100 rpm
Starting enrichment (SE) valve resistance (20°C/68°F) 2.8 – 5.2 Ω
Throttle grip free play 2 – 6 mm (1/16 – 1/4 in)
ITEM STANDARD
Coolant capacity Radiator and engine 0.3 liter (0.3 US qt, 0.3 lmp qt)
Reserve tank 0.18 liter (0.19 US qt, 0.16 lmp qt)
Radiator cap relief pressure
108 – 137 kPa (1.1 – 1.4 kgf/cm
2
, 16 – 20 psi)
Thermostat Begin to open 74 – 78 °C (165 – 172 °F)
Fully open 100 °C (212 °F)
Valve lift 8 mm (0.3 in) minimum
Standard coolant concentration 1:1 mixture with soft water
