13/BRAKE
SYSTEM
Guideline
Nut, loot
brake
lever
stop
-
Hold
push
rod
and
tighten nut
Guideline
Remaining
nuts,
chassis
-
Reconnect
spring
Checking
rear
breke
lIuid
lavel
Warning
Danger
of
accidents
Failure of the
brake
system.
MB
M6
20
Nm
(14.B Ibl
It)
15
Nm
(11.1
Ibf
It)
- II the
brake
fluid
level
falls
below
the
MIN
mark,
this indicates a
leakage
in
the
brake
system
or
worn-out
brake
linings.
Check
the
brake
system
and
do
not
continue riding.
Warning
Danger
of
accidents
Reduced
braking efficiency
due
to
old
brake
fluid.
-
Change
the
brake
fluid of the front
and
rear
brake
according to the
service
schedule.
-
Stand
the vehicle upright.
-
Check
the
brake
Iluid
level
in
the sight
glass
• If there
is
an
air bubble
in
the sight
glass
visible:
-
Add
brake
fluid to the
rear
brake
circuit. (
--
p.
104)
Adding
breke
lIuid
to
tile
rear
brake
circuit
Warning
Danger
of
accidents
Failure of the
brake
system.
- If the
brake
fluid
level
falls
below
the
MIN
mark,
this indicates a
leakage
in
the
brake
system
or
worn-out
brake
linings.
Check
the
brake
system
and
do
not
continue riding.
Warning
Skin
irritation
Brake
fluid
can
cause
skin irritation
on
contact.
-
Avoid
contact with
skin
and
eyes,
and
keep
out
of
the
reach
of children.
-
Wear
suitable protective clothing
and
goggles.
104
- If
brake
fluid
comes
into contact with the
eyes,
flush the
eyes
thoroughly with
water
and
consult a
physician
immediately.
Warning
Dan,,,
of
accidents
Reduced
braking efficiency
due
to
old
brake
fluid.
-
Change
the
brake
fluid of the front
and
rear
brake
according to the
service
schedule.
Warning
Environmental
hazard
Hazardous
substances
cause
environmental
damage.
-
Oil,
grease,
filters, fuel,
cleaners,
brake
fluid, etc.,
should
be
disposed
of
as
stipulated
in
applicable regulations.
•
Info
I
Never
use
DOT
5
brake
fluid! It
is
silicone-based
and
purple
in
color.
Oil
seals
and
brake
lines
are
not
designed
for
DOT
5
brake
fluid.
Avoid
contact
between
brake
fluid
and
painted
parts.
Brake
fluid attacks paint!
Use
only
clean
brake
fluid from a
sealed
container.
