301ENGINE
-
WORK
ON
THE
INDIVIDUAL
PARTS
Installinllhe
crankshaft
bearinl
inner
race
- Fix the crankshaft
in
the vise.
•
Info
I
Use
soft jaws.
- Slide
on
the compensating disk.
- Heat the crankshaft bearing inner
race
in
special tool
and
mount together.
Guideline
1120
°C
(248
oF)
- Repeat these steps
on
the opposite side.
- Ensure that the new crankshaft bearing inner
race
is flush.
•
Info
I After replacing the crankshaft bearings, the crankshaft
end
play must
be
measured.
Chanlinl
conn8ctinl
rod,
conrad
blarinl
and
crank
pin
Main
work
- Position the crankshaft
in
the
press
with the special tool
1 Extrude plate,
base
(77629009001)
(
~
p.
234)
- Position the special tool between the crank webs.
1 Extrude plate, top
(77629009002)
(
~
p.
234)
-
Press
the crank pin with the special tool out of the upper crank web.
1 Pressing device for crankshaft, complete
(75029047000)
(
~
p.
231)
•
Info
I Hold the lower crank
web.
-
Remove
the connecting
rod
and
bearing.
-
Press
the crank pin out of the lower crank web.
-
Press
in
the new crank pin
as
far
as
possible.
,/
Oil
hole is aligned with oil hole .
X If the oil holes
are
not correctly aligned, the conrad bearing will not
be
sup-
plied with oil.
-
Use
compressed air to check that the oil hole is clear.
