04LSHOCK
ABSORBER,
SWINGARM
Assemblinllllle
piston
rod
201416-10
201420-10
Preliminary
work
- Assemble the
seal
ring retainer. (
.-
p.
63)
Main
work
- Clamp the piston
rod
with the fork
in
a vise.
- Mount rubber buffer
and
locking cap
- Position special tool
on
the piston rod.
I Mounting sleeve (T1215) (r
p.
236)
-
Grease
the dust boot and push
seal
ring retainer onto the piston
rod.
I Lubricant (T625) (r
p.
227)
-
Remove
the special tool.
- Mount rebound washer with the cut-out facing downward.
- Mount the compression shim stack with the smaller shims facing downward.
-
Sand
both sides of piston
on
a surface plate using 1200-grit sandpaper.
-
Clean
the piston.
- Assemble the piston.
Guideline
View
Piston from
above
View
Piston from below
- Mount the rebound shim stack with the smaller shims facing upward.
64
