30JENGINE
ASSEMBLY
- Insert the needle bearings in the balancer gear
and
lubricate.
I Lubricated with engine oil
- Place the timing chain
on
the balancer gear.
e
Info
I
If
the timing chain
was
used
before, ensure
it
is running in the correct
direction.
- Mount the stop disks with the collar facing the balancer gear.
165
- Insert the timing chain, balancer gear with stop disk
and
needle bearings into the
timing chain shaft.
- Align markings
and
to
each
other.
- Mount spindle with the a-ring.
- Position the retaining bracket.
- Mount
and
tighten screws
Guideline
Screw, timing train axle
retaining bracket
M5
- Oil the starter freewheel
and
needle bearing.
6
Nm
(4.4 Ibf
ftl
- Mount freewheel gear with the needle bearing.
Loctite
e
243'"
- Ensure that the spring washers
are
seated properly. Mount the rotor.
- Mount
and
tighten screw
Guideline
Screw, rotor
MIOxl
80
Nm
(59
Ibf
ftl
Lubricated with
engine oil
