301ENGINE
ASSEMBLY
161
Installinl
til.
suction
lIum~
- Mount locking lever with the
sleeve
and spring.
- Mount and tighten screw with the
washer.
Guideline
Screw, locking lever M5
6Nm
Lactilee
243111
(4.4 Ibf
tt)
-
Push
away
locking lever from the shift drum locating unit
and
position the shift
drum locating unit
•
Info
I
The
flat
areas
of the shift drum locating unit
are
not symmetric.
- Relieve tension from the locking lever.
- Mount and tighten screw .
Guideline
Screw, shift drum locating M6
10
Nm
(7.4lbfft)
- Slide shift shaft with the washer into the bearing seat.
Lactile"'
243111
-
Push
sliding plate
away
from the shift drum locating unit. Insert the shift shaft
all the
way.
- Let sliding plate
engage
in
the shift drum locating unit.
- Shift through the transmission.
- Lubricate the oil pump shaft, internal rotor, and external rotor before assembly.
I Engine oil
(SAE
lOW/50) (
..
p.
224)
- Mount suction pump with the pin
and
oil pump shaft
•
Info
I
The
rounded side of the suction pump faces the engine
case.
- Position the oil pump
cover.
Mount
and
tighten screws
Guideline
Screw, oil pump
cover
,/
Marking faces upward.
- Insert pin
M5
6Nm
(4.4 Ibf ft)
Lactilee
243111
