Introduction Temperature (Temp)
13 - 2 V Series Operating Instructions
13.1 Introduction
This chapter describes the Temperature function in detail, including configuring alarm limits,
configuring the temperature, and taking temperature measurements.
The V 12/V 21 temperature measurement function is designed to take a continuous temperature
reading from 400 series or compatible probes.
Temp units of
°C and °F are available. Adjust the temperature units in the Setup tab.
The V 12/V 21 has three (3) potential temperature measurement sources: the TI, T2, and T Blood. Data
for up to two (2) of these sources may be simultaneously displayed.
Patient Sizes
Intended patient types: Adult, Pediatric, Neonate (with the exception of TBlood).
VPS
The VPS module supports one (1) Temperature connector (as shown in FIGURE 13-1). Refer to
"Measuring Temperature" on page 13-7 for additional information.
FIGURE 13-1 Example VPS Temp Connectors (Standalone Module on Left, VPS on Right)
Display Setup
To see the Temp values, Temp must be configured to display on the Main Screen. Refer to "Display
Options Dialog" on page 3-2 for additional information.
