V Series Operating Instructions 13 - 5
Temperature (Temp) Measuring ICT
13.3 Measuring ICT
The VPS module can interface with the Camino Advanced Monitor CAM01 in Adult, Pediatric and
Neonatal patients. The Camino measures intracranial pressure (ICP), intracranial temperature (ICT)
and calculates cerebral perfusion pressure (CePP). This section discusses setting up the Camino
device to measure ICT. Refer to the Camino Advanced Monitoring CAM01 Operating Manual for
parameter specification and setup of the Camino monitor.
NOTE: The ICT alarm limits and alarm responses are configured at the V 12/V
21 when using a Camino device.
13.3.1 Connecting to the Camino Device
One Camino supplied bedside monitor cable (as shown in FIGURE 13-4) and one Camino Adapter Kit
(as shown in FIGURE 13-5) are needed to obtain an ICT measurement.
FIGURE 13-4 Supplied Camino Cables for ICT Measurement
FIGURE 13-5 Camino Adapter Kit
Camino Temperature Cable
Camino Bedside
Monitor Cable
To Next Page
