V Series Operating Instructions 29 - 45
Product Specifications Bispectral Index (BIS) Performance
29.10 Bispectral Index (BIS) Performance
The BIS function is in accordance with the requirements of IEC 60601-2-26.
The V 12/V 21 in conjunction with:
• BIS Module
1. Performance:
The BIS parameter is capable of providing BIS in Adult, and Pediatric patients.
NOTE: The Asymmetry (ASYM) for the V 12/V 21 uses the
formula. Using will result in ASYM going from 0 to 100.
A value of 50 means there is no difference between left and right
energies.
2. BIS Alarms:
BIS function includes High and Low BIS alarms. Alarms can be triggered when measured rate is equal
to or greater/smaller than the alarm setting.
High Alarm Limits:
Low Alarm Limits:
TABLE 29-32
Measured Parameters EEG
BIS, BIS L, BIS R: 0.0 to 100.0.
Calculated Parameters
EMG, EMG L, EMG R: 25.00 dB to 100.00 dB.
SQI, SQI L, SQI R: 0.0% to 100.0%.
SR, SR L, SR R: 0.0% to 100.0%.
SEF. SEF L. SEF R: 0.50 Hz to 30.00 Hz.
sBIS L, sBIS R: 0.0 to 10.0.
sEMG L, sEMG R: 0.0 to 10.0.
TP, TP L, TP R: 40.00 dB to 100.00 dB.
ASYM, ASYM L, ASYM R: 0.0% to 100.0%.
BC, BC L, BC R: 0 bursts per minute to 30 bursts per minute.
Sweep Speed 6.25 mm/sec, 12.5 mm/sec, 25 mm/sec, 50 mm/sec, default 25 mm/sec
Input Signal Range -600 V to 600 V
Adult: Off, 10 to 99 in steps of 1, default Off
Pediatric: Off, 10 to 99 in steps of 1, default Off
Adult: Off, 1 to 90 in steps of 1, default Off
Pediatric: Off, 1 to 90 in steps of 1, default Off
