Display Options Dialog Display Setup

3 - 4 V Series Operating Instructions

3.2.2 Configuring Display Presets

Display presets are predefined display configurations or layouts. The V 12/V 21 supports 10 factory

display presets. There are five presets and five empty presets from which to choose. Configure the

presets based on the needs of the individual department or unit, clinicians preference, or the

patient’s condition. This tab and the factory default presets are described in the following section.

3.2.2.1 Display Preset Configurations

Each display preset shows the position of the digital and waveform tiles, if applicable.

Preset 1 - V 12 Monitor

TABLE 3-2 provides the factory default configuration for Preset 1.

Preset 1 - V 21 Monitor

TABLE 3-3 provides the factory default configuration for Preset 1.

TABLE 3-2

WAVEFORM TILE DIGITAL TILE

II HR

V/Vx/V1 Arrhy

Off Off

IBP1 IBP1

IBP2 IBP2

Resp Resp

Pleth SpO

NIBP NIBP List Temp 1

TABLE 3-3
