Addendum to V Series Operating Instructions 4 - 5
Mixed Venous Oxygen Saturation (SvO2) (Optional) SvO2 Setup
3. Select the buttons described in TABLE 4-3 to configure the tab.
4. Select the Ca
ncel or Accept button.
•The Cancel button closes the dialog without saving the settings.
•The Accept button saves the settings and closes the dialog.
4.3 SvO2 Setup
4.3.1 Edwards Lifesciences Monitors
For questions regarding the use and maintenance of the Edwards Vigilance
®
, Vigilance II, the Vigileoâ„¢,
and the EV1000™ monitors, refer to its operator’s manual or contact Edwards Lifesciences
Corporation for assistance. Within the USA: (800)-424-3278, outside the USA: (949)-250-2500.
The standard Edwards monitor measures both intermittent and continuous cardiac output (CCO) and
T Blood. It can also be optionally configured to measure continuous mixed venous oxygen saturation
(SvO
2
). Intermittent CO uses the bolus thermodilution method, while continuous CO uses a
pulmonary artery catheter to introduce small pulses of energy into the blood and then record the
blood temperature. SvO
2
is measured by a spectrophotometric technique that uses light emitting
diodes to transmit light in the red and infrared spectra through an optical fiber in a pulmonary artery
catheter to the blood.
The V 12/V 21 can interface with the Edwards Vigilance
®
, Vigilance II, the Vigileoâ„¢ and the EV1000â„¢.
This enables CO, T Blood and SvO
2
data to be displayed and trended at the V 12/V 21, while
providing alarm control for these parameters. The V 12/V 21 uses T Blood data from Edwards monitor
to derive ΔT which can also be displayed and trended, as well as providing alarm control.
At the V 12/V 21, the CO value is divided by the patient’s BSA (Body Surface Area) to calculate and
display a corresponding cardiac index (CI). The BSA is determined from the patient’s height and
weight as entered in the V 12/V 21.
4.3.2 Connecting to the Edwards Monitor
The following are needed to connect the V 12/V 21 to an Edwards monitor:
• Vigilance
®
, Vigilance II, Vigileoâ„¢, or EV1000â„¢
• One serial cable
NOTE: Use the serial cable supplied with the Edwards monitor to interface
with the VDI module.
• One VDI module
• One 1x slot in the V Hub or internal module bay
NOTE: Refer to "Module Status Dialog" on page 5-2 in the V Series Operating
Instructions for additional information about 1x modules.
1. Connect the serial cable to an available COM port (as shown in FIGURE 4-4) on the back side of
an Edwards monitor.
TABLE 4-3
BUTTON DESCRIPTION / COMMENTS CHOICES*
Color Configures the SvO2 parameter color. There are 16 different colors
ava
ilable. The factory default is
yellow.
* The factory default configuration settings are in bold.
To Next Page
