5 - 10
5.3 EMC Directive-Compliant System Configuration
5.3.2 Connection method
5.3.2 Connection method
Use the following methods to connect with the GOT to ensure compliance with the EMC Directive.
: Compliant with EMC Directive
: Not compliant with EMC Directive
*1: For details about each connection method, refer to the following manual.
•GOT1000 Series Connection Manual for GT Works3 and a controller used
•GOT1000 Series Connection Manual for GT Designer2/GT Works2
*2: When connecting the GOT to other controllers as a PLC manufactured by other company, create the cable (by
the user) and configure the system to meet the EMC Directive specifications for the connected device.
( 5.4.2 (8)PLC (manufactured by other company), microcomputer, temperature controller, inverter, servo
amplifier, CNC, MODBUS(R)/RTU or MODBUS(R)/TCP connection)
Connected devices
If connecting to the PLC or microcomputer other than Mitsubishi products
(MELSEC-Q series, MELSEC-L series, MELSEC-QnA series or MELSEC-A series)
please refer to the EMC Directive compliance manual for that specific device.
Connection method GT15
Bus connection
Direct connection to CPU
Computer link connection
MELSECNET/H connection (PLC to PLC network)
MELSECNET/10 connection (PLC to PLC network)
CC-Link IE Controller Network connection
CC-Link IE Field Network connection
CC-Link connection (intelligent device station)
CC-Link connection (via G4)
Ethernet connection
GOT multi-drop connection
Other connections
*2
To Next Page
