18.3 BootOS and Standard Monitor OS Installation Using Memory Card
18.3.2 Installation method using the program/data control function (Utility)
18 - 6
17
ADDITION TIMES RESET
FOR MAINTENANCE TIME
NOTIFICATION
18
INSTALLATION OF
COREOS, BOOTOS AND
STANDARD MONITOR OS
19
MAINTENANCE AND
INSPECTION
20
TROUBLESHOOTING
APPENDICESINDEX
4 BootOS, standard monitor OS is installed in the built-in flash memory.
The CF card access LED is lit during install execution.
Do not pull out the CF card or power OFF the GOT while the CF card access LED is lit.
5 GOT restarts automatically after installation is completed.
(When standard monitor OS is already installed, GOT restarts by touching button.)
6 After confirming normal restart, switch OFF the CF card access switch of GOT. When it is confirmed that
CF card access LED is not lit, remove the CF card from the CF card interface of GOT.
18.3.2 Installation method using the program/data control function (Utility)
For details of program/data control function, refer to the following.
13. FILE DISPLAY AND COPY (PROGRAM/DATA CONTROL)
Precautions on executing program/data control function
When execute program/data control function, standard monitor OS has to be
installed in GOT in advance. Thus, this function cannot be used for the initial
installation of BootOS, standard monitor OS after purchasing GOT.
Install standard monitor OS by the following two methods.
(1) GT Designer3 or GT Designer2
(2) Installing when starting the GOT
1 Operation procedure
1 Power OFF the GOT. After CF card access LED is off, install the CF card in which BootOS, standard
monitor OS or project data is stored in the CF card interface of GOT.
2 Switch ON the CF card access switch of GOT.
Now installing BootOS.
Reboot.
To Next Page
