14 - 14
14.5 Font Check
14.5.3 Font check operation
14.5.3 Font check operation
Font check starts by touching [Font Check] in the [Display check] screen.
The character data of the built-in font (in the built-in flash memory) can be checked visually to confirm the
font drawings by displaying the character data serially on the screen.
1 Before execute font check
Touching the upper right part of the screen proceeds to
the next check in each step during Font check.
Touching the upper left part of the screen returns to the
[Display check] screen.
The installed font data is displayed by touching
the upper right part of the screen.
1
2
3
4
5
6
7
8
9
10
Option fonts
To display optional fonts, the followings are required.
• The option font installation
• Option function board installation
The option fonts are displayed at the end.
11
Upper-left touch
position
Upper-right touch
position
Font data
