14.2 Self check
14.2.1 Self check function
14.2 Self check
14.2.1 Self check function
Carries out self-check of screen data or memory etc. The items which can be self-checked are as follows.
Items Description Reference page
Memory check
Carries out write/read check of the memory card and built-in flash memory
[Password]
14-5
Drawing Check Carries out missing bit check, color check and drawing check. 14-8
Font check Displays the character data on the screen to check visually. 14-13
Touch panel Check
Checks whether there are no dead zone area in the Touch key minimum unit
(16 dots x 16 dots).
14-15
I/O check Carries out RS-232 connecting target confirmation and self-loopback check. 14-17
NETWK unit status
display
Displays the LED status, error information, etc. of the installed MELSECNET/H
communication unit, CC-Link IE Controller Network communication unit, CC-Link
IE Field Network communication unit or CC-Link communication unit (GT15-
J61BT13).
14-35
