Mitsubishi GOT1000 GT15 User Manual

13.2 OS Information
13.2.3 Display example of OS information
13 - 9
9
UTILITY FUNCTION
10
COMMUNICATION INTERFACE SETTING
11
DISPLAY AND OPERATION SETTINGS
12
CLOCK SETTINGS AND BATTERY STATUS DISPLAY
13
FILE DISPLAY AND COPY
14
GOT SELF CHECK
15
CLEANING OF DISPLAY SECTION
16
MAINTENANCE TIME NOTIFICATION SETTING
13.2.3 Display example of OS information
Remark
Displayed folders and files
For the folders and files displayed, refer to the following.
13.1.5 Display file
Number Item Description
(1) Select drive
The target drive which displays file or folder can be selected.
When the CF card is not installed, [A: Built-in CF Card] / [B: Memory card] are
not displayed.
(2) Kind
Indicates whether the displayed name is for file or folder.
In case of file, displays the extension; in case of folder, displays "DIR".
(3) Name
The file name or folder name which is stored in the selected drive or folder is
displayed.
When the file name or folder name exceeds 20 characters, the exceeding
characters (the 21th character or after) are not displayed.
(4) Path name The path name of the currently displayed drive/folder is displayed.
(5) Size Displays the size of the file displayed in Name.
(6) Date and time The date and time when each file was created are displayed.
(7) The size of drive
Displays the size in use and the entire size of the drive which is selected by
drive selection.(Only the size in use is displayed when selecting the C drive.)
(8) Operation switch Execution switch of each function.
(9)
Number of folders and
files
Displays the total number of the displayed files and folders.
(1)
(2) (3)
(4)
(5) (6)
(7) (8) (9)
