14.
GOT SELF CHECK (DEBUG & SELF CHECK)
The GOT can display the screen for debugging or self-checking.
The following describes the functions available as the debugging and self checking function.
14.1 Debug
In this manual, the overview of the debuggingfunction and the operation procedure until displaying the
screen are described.
For display contents and operation procedure of debuggings, refer to the following manual.
• GOT1000 Series User's Manual (Extended Functions, Option Functions)
for GT Works3
• GOT1000 Series Extended/Option Functions Manual for GT Designer2/GT Works2
14.1.1 The Debug function
The Debug function is designed to confirm the device status of PLC CPU and to make the response for PLC
system trouble more efficient.
The following shows the functions that can be performed with the Debug function.
Item Description Reference page
Debug
System monitor, Ladder monitor, A list editor, List editor for MELSEC-A,
intelligent module monitor, Network monitor, Q motion monitor, servo
amplifier monitor, CNC monitor, Backup/restoration, and CNC data I/O,
SFC monitor, Ladder editor, Motion SFC monitor
14-1
Self check
Memory check, Drawing check, Font check, Touch panel check, I/O check,
NETWK unit status display
14-4
System alarm display GOT errors, CPU errors, network errors 14-35
GOT start time Time when the GOT was started 14-37
Operator info.
Management
Operator management, Password change, Function setting 14-39
Fingerprint
authentication
Administrator password setting, Contents registered list 14-58
Item Description
Compatible
GT
Designer2
Compatible
GT Works3
System monitor
The device of PLC CPU and buffer memory of intelligent function
module can be monitored or tested.
Ladder monitor The program of PLC CPU can be monitored in ladder format.
A list editor The sequence program of ACPU can be list edited.
FX list editor The sequence program of FXCPU can be list edited.
Intelligent unit monitor
Buffer memory in the intelligent function module can be monitored
or the data can be changed on the dedicated screen.
And the signal status of I/O modules can be monitored.
To Next Page
