3.3 Power Supply Specifications
3.3.2 For GOTs powered from the 24VDC power supply
3.3.2 For GOTs powered from the 24VDC power supply
Item
Specifications
GT1595-XTBD
GT1585V-STBD,
GT1585-STBD
GT1575V-STBD,
GT1575-STBD,
GT1575-VTBD,
GT1575-VNBD,
GT1572-VNBD,
GT1565-VTBD,
GT1562-VNBD
GT1555-V GT1555-QTBD GT1555-QSBD GT1550-QLBD
Input power
supply voltage
24VDC (+25%, -20%)
Power
consumption
57W or less
(2380mA/
24VDC)
43W or less
(1790mA/
24VDC)
41W or less
(1710mA/
24VDC)
19W or less
(790mA/
24VDC)
18W or less
(750mA/
24VDC)
17W or less
(710mA/
24VDC)
15W or less
(620mA/
24VDC)
At backlight
off
32W or less
(1330mA/
24VDC)
30W or less
(1250mA/24VDC)
14W or less
(580mA/
24VDC)
13W or less (540mA/24VDC)
Inrush current
100A or less
(4ms)
(maximum
load)
115A or less
(1ms)(maximum load)
67A or less
(1ms)(maxim
um load)
60A or less (1ms)(maximum load)
Allowable
momentary power
failure time
10 ms or less
Noise immunity
500Vp-p noise voltage, 1 s noise width (when measuring with a noise simulator under 25 to 60Hz
noise frequency)
Dielectric
withstand voltage
500VDC for 1 minute across power terminals and earth
Insulation
resistance
10M or more across power terminals and earth by a 500V DC insulation resistance tester
Applicable wire
size
0.75 to 2 [mm²]
Applicable
solderless
terminal
Solderess terminal for M3 screw RAV1.25-3, V2-S3.3, V2-N3A, FV2-N3A
Applicable
tightening torque
(Terminal block
terminal screw)
0.5 to 0.8 [N•m]
