14 - 18

14.7 I/O Check

14.7.2 Display operation of I/O Check

Main menu Debug & self check Self check

I/O check

Touch

[Debug & self check]

Touch

[I/O check]

Touch

[Self check]

( 9.3 Utility Display)
