The communication unit is used to relate the GOT extension interfaces to the system at the connection
destination.
To connect the communication unit, make Communication Settings for communications with a PLC.
For details of connection, refer to the following manual.
•GOT1000 Series Connection Manual for GT Works3 and a controller used
•GOT1000 Series Connection Manual for GT Designer2/GT Works2
8.1.1 Applicable communication unit
The following communication units are applicable for GT15.
Product name Model Description
Bus connection unit
GT15-QBUS
*1
For QCPU (Q mode)/motion
controller CPU (Q series)
connection (standard model)
For last GOT,
Number of IN side connectors: 1
For 15",
12.1",
10.4",
8.4",
5.7"
GT15-QBUS2
*1
For intermediary and last GOT,
Number of IN and OUT side
connectors: 1 for each side
GT15-ABUS
*1
For A/QnACPU/motion
controller CPU (A series)
connection (standard model)
For last GOT,
Number of IN side connectors: 1
GT15-ABUS2
*1
For intermediary and last GOT,
Number of IN and OUT side
connectors: 1 for each side
GT15-75QBUSL
For QCPU (Q mode)/motion
controller CPU (Q series)
connection (slim model)
For last GOT,
Number of IN side connectors: 1
GT15-75QBUS2L
For intermediary and last GOT,
Number of IN and OUT side
connectors: 1 for each side
GT15-75ABUSL
For A/QnACPU/motion
controller CPU (A series)
connection (slim model)
For last GOT,
Number of IN side connectors: 1
GT15-75ABUS2L
For intermediary and last GOT,
Number of IN and OUT side
connectors: 1 for each side
Serial communication
unit
GT15-RS2-9P
*1
For RS-232 interface connection, connector type
GT15-RS4-9S
*1
For RS-422 interface connection, connector type
GT15-RS4-TE
*1
For RS-422 interface connection, terminal block type
Ethernet
communication unit
GT15-J71E71-100 Ethernet (100Base-TX/10Base-T) unit
MELSECNET/H
communication unit
GT15-J71LP23-25
*2
Optical double loop unit
GT15-J71BR13
*2
Coaxial bus unit
