13.3 Project Information
13.3.3 Display example of project information
13 - 17
9
UTILITY FUNCTION
10
COMMUNICATION
INTERFACE
SETTING
11
DISPLAY AND
OPERATION
SETTINGS
12
CLOCK SETTINGS
AND BATTERY
STATUS DISPLAY
13
FILE DISPLAY AND
COPY
14
GOT SELF CHECK
15
CLEANING OF
DISPLAY SECTION
16
MAINTENANCE
TIME NOTIFICATION
SETTING
13.3.3 Display example of project information
Displayed folders and files
For the folders and files displayed, refer to the following.
13.1.5 Display file
Number Item Description
(1) Select drive
The drive by which a file or folder is displayed can be selected.
When the CF card is not connected, [A: Built-in CF card] and [B: Memory
card] are not displayed.
(2) Name
The project data (Project Folder) in the selected drive is displayed.
When the name exceeds 18 characters, the 19th and later characters are not
displayed.
The project data being monitored on the GOT is preceded by "*%".
(3) Path name Displays the path name of drive/folder which is currently displayed.
(4) Size Displays the size of the file displayed in Name.
(5) Date and time Displays the date and time when each file is installed.
(6) The size of drive
Displays the size in use and the entire size of the drive which is selected by
drive selection. (Only the size in use is displayed when selecting the C drive.)
(7) Operation switch
Displays the execution switch of functions (download, upload, etc.) which can
be carried out in [Project information].
(8)
Number of folders and
files
Displays the total number of the displayed files and folders.
(1) (2) (3) (4) (5)
(6) (7) (8)
