3 - 6
3.2 Performance Specifications
3.2.2 GT1585V-S, GT1585-S
3.2.2 GT1585V-S, GT1585-S
(Continued to next page)
Item
Specifications
GT1585V-STBA GT1585V-STBD GT1585-STBA GT1585-STBD
Display
section*1
Type TFT color liquid crystal display (High intensity and wide angle view)
Screen size 12.1”
Resolution 800 600 dots
Display size 246(9.69)(W) 184.5(7.26)(H) [mm](inch)
Display character
16-dot standard font: 50 characters 37 lines (2byte character)
12-dot standard font: 66 characters 50 lines (2byte character)
Display color
65536 colors
*2
Display angle
Left/Right: 60 degrees
Top: 40 degrees
Bottom: 50 degrees
Left/Right:65 degrees
Top:45 degrees
Bottom:55 degrees
Intensity of LCD only
350 [cd/m
2
] 400 [cd/m
2
]
Intensity adjustment 8-level adjustment
Life Approx. 50,000 h (Operating ambient temperature: 25°C)
Backlight
Cold cathode fluorescent tube (replaceable) backlight shutoff detection function is
included.
Backlight off/screen saving time can be set.
Life
*3
Approx. 50,000 h or longer
(Time when display luminance reaches 50% at the operating ambient temperature
of 25
°C)
Touch
panel
*7
Type Matrix resistive film
Number of touch keys 1,900 objects/screen (38 lines 50 columns)
Key size Minimum 16 16 dots (16 8 dots for the last line only) (per key)
Number of objects that
can be simultaneously
touched
Maximum of 2 objects
Life 1 million times or more (operating force 0.98N max.)
Human
Sensor
Detection length 1(39.37) [m](inch)
Detection range Left/Right/Top/Bottom: 70 degrees
Detection delay time 0 to 4s
Detection temperature Temperature difference between human body and ambient air: 4°C or higher
Memory
*4
C drive Built-in flash memory 9Mbytes (for storing project data and OS)
Life (Number of
write times)
100,000 times
Battery GT15-BAT lithium battery (Option)
Backup target Clock data and maintenance time notification data
Life Approx. 5 years (Operating ambient temperature of 25
°C)
To Next Page
