8 - 54
8.14 USB Environmental Protection Cover
8.14.1 Applicable USB environmental protection cover
8.14 USB Environmental Protection Cover
The USB environment cover protects the USB connector on the front face of GOT from dust, water, and oil.
The GOT is installed with the USB environment cover at factory shipment.
Replace when damage and deterioration are caused.
8.14.1 Applicable USB environmental protection cover
The following USB environmental protection cover is applicable for GT15 .
8.14.2 Installing procedure
1 Fix the USB environmental protection cover to the GOT by tightening its upper fixing screw within the
specified torque range (0.36 to 0.48 N·m). (It is advisable to set the USB environmental protection cover
along a guiding hole which is provided in the GOT, as it will make the installation easier.)
2 When the USB interface is not used, also tighten the lower fixing screw of the USB environmental
protection cover within the specified torque range (0.36 to 0.48 N·m). (IP67 compliant)
Model Description
GT15-UCOV
Environmental cover for USB interface on the GOT main unit front side
(For complying IP67)
(For 15", 12.1", 10.4", 8.4")
GT11-50UCOV
Environmental cover for USB interface on the GOT main unit front side
(For complying IP67)
(For 5.7")
For other than GT155 For GT155
For other than GT155 For GT155
Guiding hole
To Next Page
