8.17 Multi-Color Display Board
8.17.1 Applicable multi-color display board
8 - 61
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
PART NAME AND SETTINGS
5
EMC AND LOW VOLTAGE DIRECTIVE
6
INSTALLATION
7
WIRING
8
OPTION
8.17 Multi-Color Display Board
The multi-color display board is used when supporting 65536 display colors.
Depending on the function version of the GOT to be used, 65536 colors are available without the multi-color
display board.
For GOTs requiring installation of the multi-color display board, refer to the following.
3.2 Performance Specifications
8.17.1 Applicable multi-color display board
The following multi-color display board is applicable for GT15 .
*1: To use it for a SVGA or VGA GOT, install the following OS to the GOT.
(Cannot be used for a SVGA or VGA GOT without installing the OS.)
For how to install the OS, refer to GT Designer3 Version1 Screen Design Manual (Fundamentals) or GT
Designer2 Version Basic Operation/Data Transfer Manual.
When using GT1575-VN, GT1572-VN, GT1562-VN
For GT1575-VN, GT1572-VN and GT1562-VN, 65536 color display is not supported
even with the multi-color display board installed.
Model Description
GT15-XHNB
Multi-color display board for XGA (For 65536-color display)
Multi-color display board for SVGA/VGA (For 65536-color display)
*1
GT15-VHNB Multi-color display board for SVGA/VGA (For 65536-color display)
BootOS Ver. 02.01.00.E or later
Standard monitor OS: Ver. 02.01.00 or later
