Screen
Screen settings:
Optimise the contrast.
Possible values: +8 to -8
Factory setting: 0
Visualisation of the stick trim positions in the lower
corners of the screen.
Possible values: 0 to 5 (6 designs)
Factory settings: 0
Menu direction
Direction of menu navigation (see chapter 6 "Operating the transmitter" on
page 160).
5.3.9 User data
Personal data, the PIN for locking data entry, the menu language and free text
(max. 32 characters) can be configured in this menu to customise the transmitter
according to your needs.
PIN
Any PIN entry that differs from the pre-set value 0000 activates the code lock.
Entering 0000 deactivates the lock.
When the code lock is active the user is prompted for the PIN before an input
field is opened. The PIN is entered via the buttons on the keypad. The PIN
must be known in order to be able to change any settings.
If you have forgotten the PIN the code lock cannot be deactivated: Please
contact one of our Service Centres.
