Multiplex PROFI TX 9 User Manual

Model templates
PROFI TX
Page 83
4.3.3 TRACKED V. model template
This model template is suitable for tracked vehicles.
Control function assignments and names can be changed as required.
Completed tracked vehicle models typically contain a functional building block that
combines "Throttle" and "Steering" for the two power systems.
If you are using 2 separate speed controllers, it is recommended to change the
servo assignment for Steering and Throttle to TRACK+ (page 142).
TRACK+ stands for a mixer that combines "Throttle" and "Steering". You configure
the required settings in the £ Mixer menu (page 126).
Set a small deadband value in the mixer for Steering. If "Steering" and "Throttle"
are assigned to the same stick unit, opening the throttle often involves a small
steering movement. Applying a deadband to "Steering" solves this problem.
To personalise control, 4 mixers on the control side and 6 mixers on the servo side
are provided, each with eight outputs.
Controls assignment, control function, and settings
Control function
Control
Setting
Parameter
Turret turn
Horizontal stick axis.
Assignment by
means of controls
mode.
Trim
FP4
Step size
Expo
FP4
D/R
Travel
FP4
0%
1.5%
0%
100%
100%
Gun up/down
Vertical stick axis.
Assignment by
means of controls
mode.
Trim
FP4
Step size
Expo
FP4
D/R
Travel
FP4
0%
1.5%
0%
100%
100%
Steering
Horizontal stick axis.
Assignment by
means of controls
mode.
Trim
FP4
Step size
Expo
FP4
D/R
Travel
FP4
0%
1.5%
0%
100%
100%
