Operating the transmitter
PROFI TX
Page 171
6.4.2 Assigning switches
Switches are controls that toggle functions or switch functions on/off.
Switches are assigned in the Setup > Assign.Switches menu (see section 5.3.6
"Assign.Switches" on page 102). This menu includes a list of the switchable
functions provided in the software.
You can use this menu to customise the switches assignment according to your
needs.
To assign a switch proceed as follows:
1. Move the input cursor to the control function you wish to assign a switch to.
2. Open the desired input field.
3. Assign the desired switch by operating it.
4. Set the switch to the ON position or select it using the REV/CLR button.
5. Close the input field.
List of switched functions
Switch
Description
DR aileron
Dual rate (switching between travels) for the aileron signal
DR elevator
Dual rate (switching between travels) for the elevator signal
DR rudder
Dual rate (switching between travels) for the rudder signal
CS/DTC
 Combi-Switch (fixed-wing models)
 Direct Throttle Control (helicopters)
Throttle-Cut
For switching the motor off.
