PROFI TX
3.3.5 Installing additional modules
You can add four modules to the PROFI TX.
Never install two identical modules!
When these operating instructions were released for print, only the COPILOT module
(item no. 45184) was available (see section 10.2 "Accessories" on page 213).
To install a module proceed as follows:
1
Switch off the transmitter.
2
Disconnect the headset and USB cables.
3
Open the transmitter.
4
Insert the module in one of the
4 slots and make sure that the
respective fixing clip faces the
transmitter centre and is aligned
with a fixing bore on the central
plastic part.
5
Tighten the screw supplied.
Do not apply excessive force when
tightening the screw.
6
Close the transmitter.
7
Switch on the transmitter.
8
Verify that the module operates correctly. Refer to chapter "Trainer mode" on
page 50 for more information.
