4.1.1 BASIC model template
This model template is designed for simple power or glider-type models and for
models without aileron. On account of its simplicity this model template is ideally
suited to model flying simulators.
Servo assignment
If you install a second aileron servo to provide separate linkage for the ailerons,
simply assign the Aileron function to a free servo (see "Assignment" starting
from page 142). Would you like to raise the ailerons as an airbrake? In that case,
assign the AILERONS+ mixer to both aileron servos at the same position. In the
extended state, the airbrake will cause major load distribution changes: Change
the elevator to ELEVATOR+. It is then possible to compensate for the effects of
Throttle and Spoiler (airbrake).
Pre-defined mixers on the control side, with 2 more that can be defined by
the operator.
Makes it easier to fly accurate turns:
Fig. 8: BASIC servo assignment
