Frame time elapsed
Once started the timer runs until the frame time has elapsed, regardless of the
position of the assigned switch. Only then, the switch becomes effective again.
Usage as a sum timer
If no alarm time is set (0:00:00), it works like a sum timer: It sums up the times
during which the assigned switch is set to ON.
Alarm
The following alarms are issued:
Starting 10 seconds before the alarm time elapses, one brief beep per second
(, …)
When the alarm time has elapsed, one long beep (╒═╕)
The single beep identifies the timer as the frame timer.
Refer to "Configuring timers" on page 149 for detailed configuration
information.
5.7.3 Sum
This timer sums up times. It runs as long as the assigned switch is set to ON.
The timer starts at zero, counts up, sums up the times and is started and stopped
using the assigned switch.
You can reset it to zero in this menu or in status display #3 using the REV/CLR
button.
Alarm
The following alarms are issued:
Starting 5 minutes before the alarm time elapses, one double beep per
minute ()
Starting 1 minute before the alarm time elapses, one double beep every
10 seconds ()
