Multiplex PROFI TX 9 User Manual

Model templates
Page 74
PROFI TX
4.2.2 eHeli FBL model template
In the basic configuration, this model template is optimised for helicopters with
flybarless controller. The classic configuration can easily be restored by assigning
tail rotor mixers and main rotor mixers on the servo side.
The template is equally suited to collective pitch-controlled electric helicopters with
mechanical main rotor mixer. The "Governor mode" option is activated for Throttle.
Switch off this option if you prefer to work with throttle curves (see "Throttle
(helicopter)", page 118).
Servo assignment
Servo
FBL assignment
Classic assignment with mixers
(restore to flybars)
1
Aileron
MAINROTOR-FB
2
Elevator
MAINROTOR-L.
3
Rudder
TAIL ROTOR
4
Collective
MAINROTOR-R.
5
Throttle
Throttle
6
Gyro
Gyro
7..16
--------- (free)
