Multiplex PROFI TX 9 User Manual

Operating the transmitter
PROFI TX
Page 169
Assignment list
To assign a control function proceed as follows:
1. Move the input cursor to the control function you wish to assign a control to.
2. Open the input field.
3. Assign a control by pressing the + / – buttons, by using the central wheel or by
operating the control.
4. To set the actuation direction keep the control in the desired zero position and
close the input field. Alternatively, you can invert, erase or reset the control by
pressing the REV/CLR button, if required.
You can freely assign 21 physical and 6 logical controls to the following 12 control
functions:
Icon
Control
‡
Free stick that is not assigned to aileron, rudder or
elevator.
E, F
E = left slider, F = right slider
G, H
G = slider on the far left, H = slider on the far right
<1,<2,<3,<4,<5,<6,<7
Installation slots on the front left side for switches,
buttons, and rotary potentiometers
1>,2>,3>,4>,5>,6>,7>
Installation slots on the front right side for switches,
buttons, and rotary potentiometers
<¢
Left stick button/switch
¢>
Right stick button/switch
MS1, MS2
MagicSwitches (logical controls)
Fp1, Fp2, Fp3, Fp4
Flight phases (logical controls)
